HOW TO SETUP NFS SERVER (NETWORK FILE SYSTEM) ON REDHAT/CENTOS/FEDORA
Setup NFS Server in Linux
What is NFS Server?
In this artical we are going to learn how to configure NFS Server (Network File System) as well as on Client in Linux. NFS Stands for ( Network File System ) also known as Linux File Server is a Network service in Linux used to share the File System/Directory of the Server to Users/clients on the network like Map Drive in Windows Systems and user can access and store data on Central Location but This can be Possible only between Linux to Linux Systems or between Linux to Unix (Such as Vmware, Solaris Operating Systems) Systems. We also can access the share drive in Windows System but through Samba. The Port Number of NFS is 2049.
This NFS Protocol was first introduced by Sun Microsystem in 1984. The versions of NFS has been released over the time i.e. NFS, NFSv2, NFSv3, NFSv4.
Let’s take a Scenario like In a Organisation we have some data which suppose to be access by all users, in that case instead of go and copy the data in all users system manually, we can setup NFS Server and put the data on the exported Directory then Share the Directory to all users to access the data Centrally. Thin Client users also can use NFS to store their data centrally and their login Profiles can be stored in NFS shared drive as thin client doesn’t have Hardisk.
NFS DAEMONS
NFS Server uses several daemons to make available the exported directory from server to client computers over TCP/IP network and performs so many other tasks such as mount and unmount exported file system, disk quota management, map client requests to NFS daemons and So on. The daemons are listed below :
• rpc.nfsd
• rpc.mountd
• rpc.portmapper
• rpc.rquotad
• rpc.statd
• rpc.lockd
MY SCENARIO
NFS Server :-
Hostname – Computer1
IP Address :- 192.168.0.106
Operating System – Linux
NFS Client :-
Hostname – Computer2
IP Address – 192.168.0.105
Operating System – Linux
As per above scenario we have two Computers i.e. Computer1 & Computer2 out of which Computer1 is going to be configured as a NFS Server and Computer2 as a NFS Client and Both computers are in same network where “Computer1 has IP Address 192.168.0.106” and “Computer2 has IP Address 192.168.0.105”
So let’s have look at steps of NFS Server Configuration and Client Side configuration in Linux.
NFS Server Side Configuration :
Step: 1 Install Required Packages
We need to install below mentioned Packages to Configure NFS.
nfs-utils.xxx.xxx.rpm
nfs-utils-lib.xxx.xxx.rpm
portmap.xxx.xxx.rpm
system-config-nfs.xxx.xxx.rpm (For Graphical configuration of NFS)
Install the above Packages by below command.
As we can see above we have installed all required packages for NFS, Now let’s go ahead and configure the NFS from Server Side.
Step:2 Configure NFS in “/etc/exports”
Here we are going to Create three Directories named “applications” , “common” and “backup“in “/” and create some files in all created directories, Follow the below steps.
# mkdir /applications
# touch /applications/doc{1,2,3,4,5}.txt
# ls /applications/
doc1.txt doc2.txt doc3.txt doc4.txt doc5.txt
# mkdir /common
# touch /common/data{1,2,3,4,5}.txt
# ls /common/
data1.txt data2.txt data3.txt data4.txt data5.txt
# mkdir /backup
# touch /backup/test{1,2,3,4,5}.txt
# ls /backup/
test1.txt test2.txt test3.txt test4.txt test5.txt
I have created three directories to export all them in /etc/exports file so that I can explain at least three different examples.Now give Full access to all created directories by using chmod command as shown below.
# chmod 777 /applications/ /common/ /backup/
# Output:
drwxrwxrwx 2 root root 4096 Dec 25 00:05 applications
drwxrwxrwx 2 root root 4096 Dec 25 00:08 backup
drwxrwxrwx 2 root root 4096 Dec 25 00:07 common
Now let’s configure the main configuration file i.e. “/etc/exports”.
By Default the “/etc/exports” file would be empty, Now here we will export our “/applications“, “/common” and “/backup” directories by edit the “/etc/exports” Configuration file, Follow the below Steps.
Format of an entry in the “/etc/exports” file shown below.
directory-pathname host-designation(options)
Example: 1
Here I am going to export the Directory /common with Everyone (all Users/Networks) with Read/Write (i.e. rw) and Synchronize access (i.e. sync), Follow the below steps.
# nano /etc/common /applications *(rw,sync)
Note: Here “*” means we have allowed the “/common” directory with Everyone So that any can access the directory and can store their data in this.
Example: 2
To share the directory with a Particular user you have just mention the IP Address of that System, Here we have shared the /applications Directory with a single system with IP Address 192.168.0.10 with Read Only (i.e. ro), and Synchronize Permissions (i.e. sync).
# nano /etc/applications /applications 192.168.0.10(ro,sync)
Example: 3
Below scenarios configured to share the directory with all Hosts that is comes under network 192.168.0.0 with Netmask 255.255.255.0. with Read Only and Synchronize Permissions.
# nano /etc/backup /applications 192.168.0.0/24(ro,sync)
NFS Basic Permission Options
ro – Allows only Read-Only Access
rw – Allows Read/Write Access
sync – Performs all writes when Requested.
async – Performs all writes when server is busy.
Now save the Configuration File then run the below command to activate the Export List.
# exportfs -rav exporting *:/applications
Where:
- r – Re-Export all Directories
- a – Export or unexport all Directories
- v – When Exporting and Unexporting shows whats going on.
“exportfs” command used to maintain list of NFS exported file systems.
Now Start the nfs and portmap service by using below command.
# /etc/init.d/nfs start Starting NFS services: [ OK ] Starting NFS quotas: [ OK ] Starting NFS daemon: [ OK ] Starting NFS mountd: [ OK ] # /etc/init.d/portmap start Starting portmap: [ OK ]
Start all the services on startup by using below command.
# chkconfig --level 35 nfs on # chkconfig --level 35 portmap on
Now we have Done all required configurations from Server end, Now It’s time to check from NFS Client Side i.e. on Computer2.
Step:3 Configure NFS from Client Side
So Let’s have a look at the steps to configure NFS Client.
Before mount the NFS Server share directories from client side let’s check which directories been shared from Server Side by using below command.
# showmount -e 192.168.0.106 Export list for 192.168.0.106: /applications *
Note: Mention the IP Address of the Server.
1. Mount NFS shares manually :-
NFS manually mounting command format shown below.
mount -t <nfs-type> <host>:</remote/export> </local/directory>
So to mount the Exported NFS directory from client side just created a directory and run the below command, Here I have created a directory /nfs to mount the shraed directory “applications“.
# mount -t nfs 192.168.0.106:/applications/ /nfs/
Where:
<nfs-type> : Version of nfs you are using For Example NFS, NFS2, NFS3, NFS4.
<host> : IP Address of the NFS Server.
</remote/export> : Exported Directory Path from Server.
</local/directory> : Directory Path where you are going to mount the NFS exported directory.
After mounting the file system use the below command to refresh the mount table by using command mount -a and then run the command df -h to check the mounted file systems.
# mount -a # To Refresh the Mount Table
# df -h
Filesystem Size Used Avail Use% Mounted on
/dev/sda1 18G 3.1G 14G 19% /
tmpfs 252M 0 252M 0% /dev/shm
192.168.0.106:/applications/
18G 3.1G 14G 19% /nfs
Replace the <host> with the remote host(IP Address of the NFS Server), </remote/export> with the remote directory being mounted, replace </local/directory> with the local directory where the remote file system is to be mounted.
Follow the below Steps to mount the NFS share Permanently in /etc/fstab.
2. Mount NFS shares in “/etc/fstab”
To mount the NFS exported directory permanently we need to enter it in /etc/fstab file, So follow the below step to do the same.
Entry for /etc/fstab Pattern shown below.
<server>:</remote/export> </local/directory> nfs <options> 0 0
192.168.0.106:/applications /nfs nfs defaults 0 0
Replace the <server> with the IP Address of the Server.
Replace the </remote/export> with the directory path exported by NFS Server.
Replace </local/directory> with the local directory where the remote file system is to be mounted.
Now for just create a File or Directory on exported directory from Server end and go and check from client side you will find the File/Directory.
